| Полностью совместим с PCI 2.1. |
| Anytime/Anywhere Access Allows remote viewing by TCP/IP. |
| Browser Support Supports MSIE or Netscape browser to view the camera fields of vision |
| Each camera has its own configuration. Each camera can define its own video source, sensitivity, video quality, alarm, mask area and name |
| Motion Detection Watch for movement detected and record the video clips |
| Mask Function Allows the users to define the environment that they do not wish to observe. You may add/customize the masked regions |
| View Log File: Browse the recorded video clips activated by motion detection and sort by year/date/time |
| Sensitivity Adjustable sensitivity levels |
| Multiple Locations Store the video clips, local or remote through network |
| Storage Recyclable Once current disk space is used, the system will delete the data of earliest date. |
| Video Frame Size: Up to 320x240 (Per camera) @ 5~15 fps
|
| |
| Supports the following video formats which including NTSC-MюBNTSC-Japan, PAL-B,D,G,H,I, PAL -MюB, PAL-N, SECAM, юBPAL-NC |
| Supports composite video(4 port) & BNC (4,9,16 port) input connectors. |
| Bundled with the following Software: Grand X-Guard (Record and Display), Remote Camera System (Internet/Intranet or modem communication), Grand File Database. |
| Supports 98/ME/2000/XP(for 4 Port only). |
| Supports Win2000 or Win XP(9 port & 16 port). |
|
Display and record each camera or any video signal simultaneously.
|
| Adjustable video source (brightness, contrast and etc.), quality, alarm, motion detection area. |
| Motion Detection: watch for movement detected and record the video clips |
| Preview size adjustable. |
| Image quality and Compression ratio adjustable |
| Allow the users to define the environment that they do not wish to observe, by adjusting mask area and sensitivity |
| Video file database management, delete, backup or review |
| Storage Recyclable: When running out of disk space, you can delete the data of earliest date. |
| Remote view through TCP/IP or IPX protocol (Internet/Intranet), fixed IP is recommended |
| Remote view through modem communication protocol (Only for 4 port). |
| Supports following network architecture: T1,T3, ADSL, ISDN, PSTN, Cable modem, Hi building etc. |
| Compression ratio (without motion detection). |
| Height Image Quality: 4:1. |
| Low Image Quality: 30:1. |
| Every camera frame rates:
4 port : 3.0 ~ 5.0 fps, 9 port : 1.5 ~ 2.0 fps, 16 port : 0.8 ~ 1.0 fps. |
|
Remote: 10/N fps (10-Base LAN) |
| Remote: 1~16fpm(modem communication) only for 4 port |
